Does not mar the shaft
Single point faced
Available with keyways
Opposing screws available
Width tolerance: +.010¡± - .030¡±
| PART NUMBER STEEL | BORE B (in) | OUTER DIAM. OD (in) | WIDTH W (in) | FORGED SET SCREW |
| SCH-49-F | 3.063 | 5 | 1.375 | 1/2-20X1 3/4 |
| SCH-50-F | 3.125 | 5 | 1.375 | 1/2-20X1 3/4 |
| SCH-51-F | 3.188 | 5 | 1.375 | 1/2-20X1 3/4 |
| SCH-52-F | 3.25 | 5 | 1.375 | 1/2-20X1 3/4 |
| SCH-53-F | 3.313 | 5.25 | 1.375 | 1/2-20X1 3/4 |
| SCH-54-F | 3.375 | 5.25 | 1.375 | 1/2-20X1 3/4 |
| SCH-55-F | 3.438 | 5.25 | 1.375 | 1/2-20X1 3/4 |
| SCH-56-F | 3.5 | 5.25 | 1.375 | 1/2-20X1 3/4 |
| SCH-57-F | 3.563 | 5.5 | 1.375 | 1/2-20X1 3/4 |
| SCH-58-F | 3.625 | 5.5 | 1.375 | 1/2-20X1 3/4 |
| SCH-59-F | 3.688 | 5.5 | 1.375 | 1/2-20X1 3/4 |
| SCH-60-F | 3.75 | 5.5 | 1.375 | 1/2-20X1 3/4 |
| SCH-61-F | 3.813 | 5.75 | 1.375 | 1/2-20X1 3/4 |
| SCH-62-F | 3.875 | 5.75 | 1.375 | 1/2-20X1 3/4 |
| SCH-63-F | 3.938 | 5.75 | 1.375 | 1/2-20X1 3/4 |
| SCH-64-F | 4 | 5.75 | 1.375 | 1/2-20X1 3/4 |
| SCH-65-F | 4.063 | 6 | 1.375 | 1/2-20X2 |
| SCH-66-F | 4.125 | 6 | 1.375 | 1/2-20X2 |
| SCH-67-F | 4.188 | 6 | 1.375 | 1/2-20X2 |
| SCH-68-F | 4.25 | 6 | 1.375 | 1/2-20X2 |
| SCH-69-F | 4.313 | 6.25 | 1.375 | 1/2-20X2 |
| SCH-70-F | 4.375 | 6.25 | 1.375 | 1/2-20X2 |
| SCH-71-F | 4.438 | 6.25 | 1.375 | 1/2-20X2 |
| SCH-72-F | 4.5 | 6.25 | 1.375 | 1/2-20X2 |
| SCH-73-F | 4.563 | 6.5 | 1.375 | 1/2-20X2 |
| SCH-74-F | 4.625 | 6.5 | 1.375 | 1/2-20X2 |
| SCH-75-F | 4.688 | 6.5 | 1.375 | 1/2-20X2 |
| SCH-76-F | 4.75 | 6.5 | 1.375 | 1/2-20X2 |
| SCH-77-F | 4.813 | 6.75 | 1.375 | 1/2-20X2 |
| SCH-78-F | 4.875 | 6.75 | 1.375 | 1/2-20X2 |
| SCH-79-F | 4.938 | 6.75 | 1.375 | 1/2-20X2 |
| SCH-80-F | 5 | 6.75 | 1.375 | 1/2-20X2 |
| SCH-81-F | 5.063 | 7 | 1.375 | 1/2-20X2 |
| SCH-82-F | 5.125 | 7 | 1.375 | 1/2-20X2 |
| SCH-83-F | 5.188 | 7 | 1.375 | 1/2-20X2 |
| SCH-84-F | 5.25 | 7 | 1.375 | 1/2-20X2 |
| SCH-85-F | 5.313 | 7.25 | 1.375 | 1/2-20X2 |
| SCH-86-F | 5.375 | 7.25 | 1.375 | 1/2-20X2 |
| SCH-87-F | 5.438 | 7.25 | 1.375 | 1/2-20X2 |
| SCH-88-F | 5.5 | 7.25 | 1.375 | 1/2-20X2 |
| SCH-89-F | 5.563 | 7.5 | 1.375 | 1/2-20X2 |
| SCH-90-F | 5.625 | 7.5 | 1.375 | 1/2-20X2 |
| SCH-91-F | 5.688 | 7.5 | 1.375 | 1/2-20X2 |
| SCH-92-F | 5.75 | 7.5 | 1.375 | 1/2-20X2 |
| SCH-93-F | 5.813 | 7.75 | 1.375 | 1/2-20X2 |
| SCH-94-F | 5.875 | 7.75 | 1.375 | 1/2-20X2 |
| SCH-95-F | 5.938 | 7.75 | 1.375 | 1/2-20X2 |
| SCH-96-F | 6 | 7.75 | 1.375 | 1/2-20X2 |
