OIC-EB-900 Sliding Door Motor

Elevate your home with the Raydafon Group's OIC-EB-900 Sliding Door Motor: a sleek, quiet motor offering effortless automation for homeowners. Its advanced tech ensures smooth operation, saving time and enhancing convenience in daily life. Stand out with superior durability and user-friendly design, making every slide a seamless experience. Trust in quality and innovation—transform your space today!

Send Inquiry

Product Description

OIC-EB-900

Supply Voltage(V)	AC230/120V
Motor Power(W)	900W
Torque	45Nm
Maximum Weight Of Gate	2000kg
Motor Rotation Speed(Rated)	1400r/min
Gate Speed	12M/Minute
Limit Switch	Spring switch/magnetic switch
Noise	≤56dB
Operating Environment Temperature	-45℃～65℃
Certificates	CCC, CE

With exquisite appearance,the main body of the high quality ABS and Aluminium through spray painting
The motor is powerful,starts smoothly,has big torque and low noise,and is smooth and reliable when operating.
With built-in thermal protector(the motor will automatically cut off power supply for protection when the motor heat up to rated temperature).
The circuit of the Photocell has the functions of electronic infrared ray collision prevention and electronic reversion when meeting obstacle so as to ensure pedestrians' safety.
Our motor is self-locking. If there is short of electric power, you only need to turn the key clockwise 90 degree, then pull the black bar about 60-90degree(more than 45 degree), then the door can move by hand. No need backup battery.
Installation is simple,easy maintenance.
