OICSV-2 Swing Gate Motor

Raydafon Group's OICSV-2 Swing Gate Motor offers reliable automation with advanced technology and durable design, ideal for homeowners seeking enhanced security and convenience. It delivers smooth operation, energy efficiency, and easy installation, solving daily access hassles while standing out with superior build quality in the market.

Send Inquiry

Product Description

Supply Voltage(V) AC230 50Hz/120V 60Hz
Motor Power(W) 150W
Stroke   500mm
Maximum Width Of Gate 5M
Maximum Weight Of Gate 1000kg
Motor Rotation Speed(Rated) 1400r/min
Gate Speed   12M/Minute
Limit Switch Mechanical Limit Switch
Noise   ≤56dB
Operating Environment Temperature   -45℃～65℃
Protection Level   IP44
Arm   Single/Double(Mention Left or Right)

With exquisite appearance,the main body of the high quality ABS and Aluminium through spray painting

The motor is powerful,starts smoothly,has big torque and low noise,and is smooth and reliable when operating.

With built-in thermal protector(the motor will automatically cut off power supply for protection when the motor heat up to rated temperature).

The circuit of the Photocell has the functions of electronic infrared ray collision prevention and electronic reversion when meeting obstacle so as to ensure pedestrians' safety.

Our motor is self-locking. If there is short of electric power, you only need to turn the key clockwise 90 degree, then pull the black bar about 60-90degree(more than 45 degree), then the door can move by hand. No need backup battery.

Installation is simple,easy maintenance.
