Moving Walk Pallet Chains

Raydafon moving walk pallet chains are precision-engineered roller chains designed for autowalk and travelator systems in airports, metro stations and large commercial complexes. Standard pitch 133.33mm, with 76×25mm inner roller, 40×5mm chain plates and 14.63mm hardened pin. Minimum tensile strength 180kN, safety factor ≥6 as required by EN 115-1. Each pallet chain set is supplied as a matched pair to ensure synchronized pallet movement and eliminate uneven wear. Manufactured from high-grade heat-treated alloy steel with hardened pins and precision-ground rollers. Compatible with Schindler 9500, KONE TravelMaster 115, OTIS and Fujitec moving walk systems. Custom chain lengths, pitch options and OEM branding available. Send chain pitch, roller dimensions, required length and quantity for a confirmed quotation within 24 working hours.

Send Inquiry

Product Description

Moving Walk Pallet Chains

Pitch 133.33mm 180kN Tensile EN 115-1 OEM/ODM

Raydafon moving walk pallet chains are precision-engineered roller chains designed for autowalk and travelator systems in airports, metro stations and large commercial complexes.

Standard pitch 133.33mm, with 76×25mm inner roller, 40×5mm chain plates and 14.63mm hardened pin. Minimum tensile strength 180kN, safety factor ≥6 as required by EN 115-1.

Each pallet chain set is supplied as a matched pair to ensure synchronized pallet movement and eliminate uneven wear. Compatible with Schindler 9500, KONE TravelMaster 115, OTIS and Fujitec moving walk systems.

Request a Quote WhatsApp

Technical Specifications

All moving walk pallet chains are manufactured to EN 115-1, GB 16899-2011 and ISO/DIN standards. The standard configuration uses high-grade heat-treated alloy steel links with hardened pins and precision-ground rollers designed to accurately engage the drive sprockets for smooth operation.

Moving walk pallet chain — key technical parameters
Parameter	Value
Chain Type	Moving walk pallet chain (endless roller type)
Standard Pitch	133.33 mm
Alternative Pitches	131.33 mm, 135.46 mm (on request)
Inner Roller Diameter	76 mm × 25 mm
Chain Plate Dimensions	Inner plate 40×5 mm, Outer plate 40×5 mm
Pin Diameter	14.63 mm (hardened)
Min. Tensile Strength	180 kN / 40,465 lbf
Average Tensile Strength	198 kN
Safety Factor	≥6 per EN 115-1
Weight per Meter	5.75 kg/m (approx.)
Chain Length Tolerance	0.010 inch across 8 ft
Operating Speed	0.5 m/s (standard)
Pallet Widths Supported	800 mm, 1000 mm, 1200 mm, 1400 mm
Compatible Systems	Schindler 9500, KONE TravelMaster 115, OTIS, Fujitec
Standards	EN 115-1, GB 16899-2011, ISO/DIN
Quality Standard	ISO 9001
Customization	OEM/ODM chain length, pitch, packaging

Typical Applications

Moving walk pallet chains are specified wherever passengers and light goods need continuous horizontal or slight-incline transport. These chains are widely used in high-traffic public buildings and transport hubs.

Airport Terminals Long-distance horizontal transport for passengers with luggage between check-in, security and boarding gates.

Metro & Railway Stations Continuous passenger flow between platforms, concourses and exits during peak hours.

Shopping Malls Comfortable horizontal transport between retail zones, parking areas and transit connections.

Convention Centers Efficient people movement during large exhibitions, trade shows and events.

How to Select the Right Pallet Chain

Identify moving walk brand and model Schindler 9500, KONE TravelMaster 115, OTIS or Fujitec — determines pitch and roller dimensions.
Confirm chain pitch Standard 133.33mm; alternative 131.33mm or 135.46mm for specific models.
Determine chain length Based on number of pallets or measured length of the existing chain run.
Verify matched pair requirement Left and right chains must be supplied as a matched set to ensure synchronized movement.
Confirm quantity and delivery Provide quantity, destination port, and whether OEM branding or custom packaging is needed.

Installation & Maintenance

Proper installation and regular maintenance extend the service life of moving walk pallet chains and ensure safe passenger transport.

Key installation and maintenance parameters
Item	Guideline
Tensioning	Automatic tensioning device required. Individual fine adjustment for each chain linkage.
Lubrication	Regular lubrication of pin and roller contact surfaces. Use chain lubricant suitable for escalator/moving walk applications.
Wear Inspection	Replace chain before reaching 1% elongation. Check for cracked links, pin failure and roller wear.
Chain Replacement	Pallets and pallet chains can be replaced independently. Chain segments can be removed individually as required.
Safety Check	Verify safety factor ≥6 before commissioning. Test certificate for chain breaking load should be available.

Ordering & Supply Information

What to send for a fast quotation

Moving walk brand and model
Chain pitch (133.33mm standard)
Required chain length or number of pallets
Quantity (matched pairs)
Destination port and OEM branding requirements

Supply terms

Sample and trial orders accepted for fitment verification
MOQ depends on stock status — confirm per order
Export packing: wooden case or pallet
Test certificate for chain breaking load provided
Lead time: 7–15 days for samples, 25–35 days for mass production

Frequently Asked Questions

What is a moving walk pallet chain and where is it used?

A moving walk pallet chain is an endless roller chain that connects and drives the pallets of a moving walkway (also called an autowalk or travelator). It is used in airport terminals, metro stations, convention centers and large shopping malls to transport passengers horizontally or at a slight incline of up to 12 degrees.

What is the standard pitch and size of moving walk pallet chains?

The standard pitch is 133.33 mm. Other common pitches include 131.33 mm and 135.46 mm depending on the moving walk brand. The inner roller is typically 76×25 mm, chain plates are 40×5 mm, and the hardened pin diameter is 14.63 mm.

What safety factor and tensile strength do your pallet chains meet?

Our moving walk pallet chains have a minimum tensile strength of 180 kN and are designed with a safety factor of at least 6 as required by EN 115-1. Each chain is supplied with a test certificate for breaking load.

Which moving walk brands are your pallet chains compatible with?

Our pallet chains are compatible with Schindler 9500, KONE TravelMaster 115, OTIS and Fujitec moving walk systems. We supply matched pairs (left and right) to ensure synchronized pallet movement. Custom chain lengths are available for specific installation requirements.

How do I order and what information should I provide?

Send the following for a confirmed quotation: chain pitch and roller dimensions, required chain length (or number of pallets), moving walk brand and model, and quantity. We accept sample orders for fitment verification. Lead time is 7-15 days for samples and 25-35 days for mass production.

Get Your Moving Walk Pallet Chain Quote

Send moving walk brand, chain pitch, required length and quantity — our engineers confirm the correct configuration and return a quotation within 24 working hours.

Request Price & Fitment Match Chat on WhatsApp
