CAPACITIES & DIMENSIONS OF TORQUE LIMITER
|
TORQUE LIMITER SIZE |
TORQUE CAPACITY (KG.M.) |
PILOT MIN. BORE |
MAX. BORE |
APPROX. WT.KG |
A |
B |
C |
D |
M MAX. |
F SPROCKET BORE DIA. OVER BUSHING |
|
|
MIN |
MAX |
||||||||||
|
50-M1 |
0.3 |
1.5 |
8.0 |
14 |
0.3 |
一50 |
29 |
24 |
6.5 |
7.2 |
30.10 |
|
50-M2 |
03 |
2.5 |
8.0 |
14 |
0.3 |
50 |
29 |
24 |
6.5 |
7.2 |
30.10 |
|
65-M1 |
07 |
2.8 |
9.6 |
22 |
0.5 |
65 |
50 |
35 |
15 |
8.8 |
41.40 |
|
65-M2 |
1.4 |
5.5 |
9.6 |
22 |
0.5 |
65 |
50 |
35 |
15 |
8.8 |
41.40 |
|
90-M1 |
2.3 |
7.0 |
12.7 |
28 |
1.5 |
90 |
65 |
45 |
18 |
16.0 |
52.00 |
|
90-M2 |
3.5 |
14.0 |
12.7 |
28 |
1.5 |
90 |
65 |
45 |
18 |
16.0 |
52.00 |
|
125-M1 |
5.3 |
18.0 |
19.0 |
38 |
3.5 |
125 |
78 |
60 |
23 |
16.0 |
70.00 |
|
125-M2 |
6.5 |
36.0 |
19.0 |
38 |
3.5 |
125 |
78 |
60 |
23 |
16.0 |
70.00 |
|
150-M1 |
7.5 |
44.0 |
25.0 |
42 |
5.5 |
150 |
90 |
70 |
26 |
23.0 |
80.00 |
|
150-M2 |
9.3 |
61.0 |
25.0 |
42 |
5.5 |
150 |
90 |
70 |
26 |
23.0 |
80.000 |
|
180-M1 |
11 0 |
58.0 |
25.0 |
64 |
10.0 |
180 |
106 |
100 |
28 |
28.5 |
110.00 |
|
180-M2 |
200 |
110.0 |
25.0 |
64 |
10.0 |
180 |
106 |
100 |
28 |
28.5 |
110.00 |
|
225-M1 |
220 |
140.0 |
30.0 |
92 |
20.0 |
230 |
120 |
140 |
33 |
28.5 |
152.0 |
|
225-M2 |
400 |
175.0 |
30.0 |
92 |
20.0 |
230 |
120 |
140 |
33 |
28.5 |
152.0 |
China Torque Limiters manufacturer, Chinese Torque Limiters supplier, produce: Torque Limiters, Friction Torque Limiters, Pilot Ball Toque Limiters, Pilot Bronze Torque Limiters, Torque Limiters Couplings Torque Limiters Adapters. We can produce as per customer's drawing or sample. Please feel free to send us your detail enquiries. E-mail: [email protected]
