Product Description

Trapezoidal Tooth H150

H150（38.1mm）
ITEM	TEETH	STRUCTURE	Dp	O.D.(De)	W	L	K	X	Dm	d	E	F	Flange I.D.	Flange Type
14H	14	A\B	56.6	55.22	45	58	40	-	38	20	-	61	41	F-156141
15H	15	A\B	60.64	59.27	45	58	40	-	46	20	-	65	50	F-156550
16H	16	A\B	64.68	63.31	45	58	40	-	46	20	-	69	50	F-156950
18H	18	A\B	72.77	71.39	45	58	40	-	55	20	-	78	58	F-157858
19H	19	A\B	76.81	75.44	45	58	40	-	56	20	-	83	63	F-158363
20H	20	A\B	80.85	79.48	45	58	40	-	58	20	-	86	66	F-158666
21H	21	A\B	84.89	83.52	45	58	40	-	58	20	-	90	69	F-159069
22H	22	A\B	88.94	87.56	45	58	40	-	62	20	-	93	75	F-159375
24H	24	A\B	97.02	96.65	45	58	40	-	66	20	-	105	84	F-1510584
25H	25	A\B	101.06	99.69	45	58	40	-	70	20	-	108	84	F-1510884
26H	26	A\B	105.11	103.73	45	58	40	-	74	20	-	112	90	F-1511290
28H	28	A\B	113.19	111.82	45	58	40	-	74	20	-	118	90	F-1511890
30H	30	A\B	121.28	119.9	45	58	40	-	78	20	-	126	100	F-15126100
32H	32	A\B	129.3	127.99	45	58	40	-	82	20	-	136	118	F-15136118
34H	34	A\B	137.45	136.07	45	60	40	-	82	20	-	146	128	F-15146128
36H	36	A\B	145.53	144.16	45	60	40	-	82	20	-	152	134	F-15152134
38H	38	A\B	153.62	152.24	45	60	40	-	88	20	-	160	140	F-15160140
40H	40	A\B	161.7	160.33	45	60	40	-	88	20	-	170	150	F-15170150
42H	42	B\W	169.79	168.41	45	60	40	15	88	20	146	-	-	-
44H	44	B\W	177.87	176.5	45	60	40	15	88	20	154	-	-	-
45H	45	B\W	181.91	180.54	45	60	40	15	88	20	158	-	-	-
48H	48	B\W	194.04	192.67	45	60	40	15	88	20	171	-	-	-
50H	50	B\W	202.13	200.76	45	60	40	15	88	20	179	-	-	-
58H	58	B\W	234.47	233.09	45	60	40	15	88	20	211	-	-	-
60H	60	B\W	242.55	241.18	45	60	40	15	88	20	219	-	-	-
70H	70	B\W	282.98	281.61	45	65	40	15	88	25	258	-	-	-
72H	72	B\W	291.06	289.69	45	65	40	15	88	25	265	-	-	-
84H	84	B\W	339.57	338.2	45	65	40	15	100	25	314	-	-	-
96H	96	B\W	388.08	386.71	45	65	40	15	100	25	362	-	-	-
120H	120	B\W	485.1	483.73	45	65	40	15	100	25	460	-	-	-

China pulleys manufacturer, chinese pulley supplier, produce: taper pulleys, adjustable pulleys, falt belts pulleys, V-belt pulleys, sheaves, V-Belt Pullys for taper bushes, V-Belt Pullys with solid hub. We can produce as per customer's drawing or sample. Please feel free to send us your detail enquiries. E-mail: [email protected]
